2. M110 Component Selection (2)
n Overview : M110 Disk Array (3.5”)
7
NEC Confidential
Controller
BBU
Switch
Switch
Base Unit
Power
Fan
電源
DE#01
電源
Switch
Switch
DE#09
Switch
Switch
Disk Enclosure
NL-SAS HDD/SAS SSD
Refer to “The Number of Disk Enclosures”
ControllerCache 8GB
BBU
Cache 8GB
NL-SAS HDD/SAS SSD
NL-SAS HDD/SAS SSD
DE#00（Built-in)
Power
Fan
Power
Disk Enclosure
Power
Fan
Fan
Host Port Card
Fan
PowerSupply
Fan
PowerSupply
SFP
SFP
Host Port Card
DISK Port DISK Port
