2. M110 Component Selection (21)
【CAUTION: The Number of Disk Enclosures】
M-Series can use a mix of 3.5” and 2.5” disk enclosures at the same time.
The sum of available disk drive slots in both base unit and disk enclosures must not exceed the
supported maximum number of disk drives. Note: Even if a disk drive slot is blank, it is still counted.
For example:
I would like to use 120 disk drives in base unit (3.5”) and four disk enclosures (2.5”).
1 x 3.5” base unit: 12 disk drives in base unit
5 x 2.5” disk enclosures: 24 disk drives in four disk enclosures. 12 disk drives in
one disk enclosure.
Is this supported? → No, it is not supported.
Max. number of disk drives of 3.5” base unit: 12
Max. number of disk drives of 2.5” disk enclosure: 24
12 (base unit) + 24 + 24 + 24 + 24 +24 = 132 disk drive slots
12 (base unit) + 24 + 24 + 24 + 24 +12 = 120 disk drives
M110 Disk Array supports disk drives up to 120. However,
the sum of available disk drive slots in base unit and disk
enclosures (132) exceeds the supported maximum number
of disk drives (120).
→ This configuration is not supported.
26
NEC Confidential
・
・
・
DE×5
DAC×1
To Next Page
