Specifi cations
Monitor Specifi cations MD211G5 Notes
LCD panel color Clear Base
LCD 21.3-inch (54 cm), monochrome, TFT active matrix, anti-glare
Pixel pitch (H x V) 0.165 x 0.165 mm
Display area (H x V) 337.9 x 422.4 mm
Pixel (H x V) 2048 x 2560
Grayscale 256 steps of gray out of a palette of 12277
Backlight Edge Light Type with white LED
LCD Optical characteristics (typ.) Viewing angle: 176° horizontal/vertical (contrast ratio ≥ 50:1)
Contrast ratio: 1200:1 (Viewing angle perpendicular to LCD panel)
Luminance DICOM calibrated 500 cd/m
2
as factory default
Maximum 600 cd/m
2
(1200 cd/m
2
typ. as LCD component)
Input sync signal DVI 1.0 compliant, DisplayPort 1.2 compliant
Available resolution 640 x 480
800 x 600
1024 x 768
2048 x 2560 (at Fv=25/50Hz)
2560 x 2048 (at Fv=25/50Hz)
Input connectors DVI 24-pin connector, DisplayPort connector
Power Supply AC 100-240 V ~ 50/60 Hz
Current Rating 1.5 - 0.6 A
USB Hub USB Rev. 2.0 compliant, Self-powered
USB upstream port (x1), USB downstream ports (x2)
Ambient conditions Temperature:
Humidity (no condensation):
Air pressure:
Operating: 5 - 35°C, Transport / Storage: -20 - 60°C
Operating: 20 - 80%, Transport / Storage: 10 - 85%
Operating: 700 - 1060hPa, Transport / Storage: 266 - 1060hPa
Dimensions & weight Net:
(W x H x D) Packed:
390 x 487.8/584 x 227.6 mm (W x H x D: Portrait) approx. 11.8 kg
475 x 705 x 345 mm (W x H x D). approx. 15.8 kg
Safety certifi cations ANSI/AAMI ES60601-1:2005, CAN/CSA-C22.2 No. 60601-1:08, FCC-B, CE-MDD, VCCI-B
NOTE: Technical specifi cations are subject to change without notice.
Troubleshooting
The display won't turn on! (The power indicator is off.)
• Make sure the display is plugged.
• Check to see if the display is turned on.
The screen is not lit!
• Check if cables are connected correctly.
• Check if the computer is turned on.
• If the LED indicator is orange, the computer may be in power saving mode. Press any key on the keyboard to wake up
the computer.
• The input signal frequency or display resolution may not be appropriate for the display. Refer to the computer instruction
manual and adjust the frequency and/or resolution.
• If the LED is red, this may be an error indication. Contact your supplier.
Images are not displayed properly!
• The display resolution may not be appropriate for the display. Refer to the computer instruction manual and adjust
resolution.
The refresh rate is set to 50Hz (dual-link mode) and resolution loss (scan line gaps) occurs!
• This can happen when a single-link cable or a DisplayPort to Single Link adapter is used. Use the supplied dual-link
cable which supports both single-link (25Hz) and dual-link (50Hz) modes, or set the refresh rate to 25Hz.
