STEP 3-B. Connect one end of the long power cord to the AC-IN
connector on the audio base and the other end into the
AC wall outlet (Figure 3-B).
STEP 4-B. Reconnect your monitor to your computer system as shown
in the monitor User’s Manual.
STEP 5-B. Turn on the audio base and adjust the controls for best
sound performance.
Controls
Power: Press the power button to turn the audio base on or off. An
indicator light next to the power button will glow to show power is on.
Volume: Turn this control clockwise to increase volume level and
counterclockwise to decrease volume level.
Headphone Output Jack: Headphones can be used to listen to audio in
private. When the headphone plug is inserted into the headphone jack,
the speakers are automatically disconnected and sound is heard through
the headphones.
NOTE: Headphones not included. The headphone plug required is a mini
stereo type measuring 3.5mm.
Short Power Cord
AC IN
Long Power Cord
Figure 3-B
E-3
