English-13
English
Controls
OSD (On-Screen Display) control keys on the front of the monitor function
are as follows:
To access OSD menu, touch any of the control keys.
To change signal input, touch the INPUT/SELECT key.
NOTE: Exit OSD in order to change signal input.
1 Ambient Light Sensor
Human Sensor
Detects the level of ambient lighting and the presence of a user, allowing the monitor to make
adjustments to various settings resulting in a more comfortable viewing experience. Do not
cover this sensor.
2 LED Indicates that the power is on or off.
3 Power Turns the monitor on and off.
4 INPUT/SELECT Enters the OSD menu. Enters OSD sub menus.
Changes the input source when not in the OSD menu. You can directly change to L/B (LOW
BLUE LIGHT) mode by touching the INPUT key for 3 seconds or more.
5 MENU/EXIT Accesses OSD menu. Exits the OSD sub menu. Exits OSD menu.
When not in the OSD menu, touch the key for a few seconds to activate RESTORE in
CUSTOMIZE SETTING.
6 LEFT/RIGHT Navigates to the left or right through the OSD menu.
You can adjust the USB SELECT directly by touching RIGHT while the OSD menu is off.*
1
DP OUT MULTISTREAM setting and TILE MATRIX ENABLE setting are changed by touching
the LEFT key for 3 seconds or more while the OSD menu is off.*
1
If DP OUT MULTISTREAM setting is CLONE, the setting will be changed to AUTO.
7 UP/DOWN Navigates up or down through the OSD menu.
You can adjust the BRIGHTNESS directly by touching UP while the OSD menu is off.*
1
You can adjust the VOLUME directly by touching DOWN while the OSD menu is off.*
1
8 /RESET Resets the OSD controls back to factory settings.
Selects MULTI PICTURE when OSD menu is off*
2
.
You can swap pictures between a main screen and a sub screen by touching the
/RESET
key for 3 seconds or more while Main or Sub is set in MULTI PICTURE.*
1,
*
3
*
1
When Hot Key function is OFF, this function is disabled.
*
2
MULTI PICTURE menu.
Touch the LEFT/RIGHT to select a priority (adjustable) screen. When MULTI PICTURE is OFF, a single screen will be
displayed.
*
3
Swapping of picture by picture is not supported. The sound keeps the value of SOUND INPUT setting.
The expansion keeps the values of EXPANSION setting of each input.
