English
English-9
AUDIO
Controls the volume of the speakers or headphones.
To mute the speaker output, press the “12/RESET” button.
BRIGHTNESS
Adjusts the overall image and background screen brightness.
To enter the ECO MODE, press the “12/RESET” button.
ECO MODE OFF: Sets brightness variable to 100%
ECO MODE1: Sets brightness to 80%.
This setting can adjust brightness to a range in which power is reduced to meet Energy Star measurement
conditions.
ECO MODE2: Sets brightness to 30%.
This setting can adjust brightness to a range in which power is reduced by 30% compared to the maximum
brightness setting.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST
Adjusts the image displayed for non-standard video inputs.
AUTO ADJUST
Automatically adjusts the Image Position, the H. Size and Fine setting.
LEFT/RIGHT
Controls Horizontal Image Position within the display area of the LCD.
DOWN/UP
Controls Vertical Image Position within the display area of the LCD.
H. SIZE
Adjusts the horizontal size by increasing or decreasing this setting.
FINE
Improves focus, clarity and image stability by increasing or decreasing this setting.
COLOUR CONTROL SYSTEMS
Five colour presets (9300/7500/sRGB/USER/NATIVE) select the desired colour setting.
COLOUR RED
Increase or decreases Red. The change will appear on screen.
COLOUR GREEN
Increase or decreases Green. The change will appear on screen.
COLOUR BLUE
Increase or decreases Blue. The change will appear on screen.
TOOL
Selecting TOOL allows you to get into the sub menu.
FACTORY PRESET
Selecting Factory Preset allows you to reset all OSD control settings back to the factory settings. The 12/RESET
button will need to be held down for several seconds to take effect. Individual settings can be reset by highlighting
the control to be reset and pressing the 12/RESET button.
EXIT
Selecting EXIT allows you exit OSD menu/ sub menu.
