Specifications
Monitor Specifications MultiSync LCD175M Monitor Notes
LCD Module Diagonal: 43 cm/17 inches Active matrix, thin film transistor (TFT) liquid
Viewable Image Size: 43 cm/17 inches crystal display (LCD); 0.264 mm dot pitch;
Native Resolution (Pixel Count): 1280 x 1024 250 cd/m
2
white luminance, 1000:1 contrast
ratio, typical.
Input Signal 15 pin Mini D-Sub: Analog RGB 0.7 Vp-p/75 Ohms
Sync Separate sync.TTL Level (Positive/Negative)
DVI-D: Digital RGB DVI (HDCP)
Audio input: Stereo Mini Jack 1 Vrms input
Output Signal Headphones: Stereo Mini Jack
Display Colours 16.7 M Depends on display card used.
Viewing Angle Left/Right: -80°/+80° (CR>10)
Up/Down: -80°/+80° (CR>10)
Synchronization Range Horizontal: 31.5 kHz to 81.1 kHz Automatically
Vertical: 56 Hz to 76 Hz Automatically
Resolutions Supported Landscape: 720 x 400*
1
: VGA text Some systems may not support all modes listed.
640 x 480*
1
at 60 Hz to 75 Hz
800 x 600*
1
at 56 Hz to 75 Hz
832 x 624*
1
at 75 Hz
1024 x 768*
1
at 60 Hz to 75 Hz
1152 x 864*
1
at 75 Hz
1152 x 870*
1
at 75 Hz
1280 x 960*
1
at 60 Hz to 75 Hz Recommended resolution is 60 Hz for optimal
1280 x 1024 at 60 Hz to 75 H...........display performance.
Active Display Area Horizontal: 337.9 mm
Vertical: 270.3 mm
Speakers Practical Audio Output: 1.0 W + 1.0 W
Power Supply 100 - 240 V ~ 50/60 Hz
Current Rating 0.5 - 0.3 A (with Audio)
Power Maximun Operation: 27 W
Consumption Normal Operation: 19 W
Dimensions Landscape: 368.0 mm (W) x 358.5 - 408.5 mm (H) x 230.0 mm (D)
14.5 inches (W) x 14.1 - 16.1 inches (H) x 9.1 inches (D)
Weight 5.2 kg (11.5 lbs)
Environmental Considerations
Operating Temperature: 5°C to 35°C/41°F to 95°F
Humidity: 20% to 80%
Altitude: 0 to 2,000 m/0 to 6,562 Feet
Storage Temperature: -10°C to 60°C/14°F to 140°F
Humidity: 10% to 85%
Altitude: 0 to 12,192 m/0 to 40,000 Feet
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on
the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
