Specifi cations
Product Specifi cations
LCD Module
Pixel Pitch:
Resolution:
Color:
Brightness:
Contrast Ratio:
Viewing Angle:
31.5”/800.4 mm diagonal
0.510 mm
1366 x 768
Over 16 million colors (depending on video card used)
450 cd/m
2
(Max.), 340 cd/m
2
(Factory setting Typ.) @25°C
3000:1
89° (typ) @ CR>10
Frequency Horizontal:
Vertical:
15.625/15.734 kHz, 31.5 kHz - 91.1 kHz (Analog Input)
31.5 kHz - 91.1 kHz (Digital Input)
50.0 - 85.0 Hz
Pixel Clock 25.2 MHz - 162.0 MHz
Viewable Size 697.7 x 392.3 mm
Input Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
, 1920X1080*
1
(60Hz), 1080p*
1
,
1080i*
1
DisplayPort DisplayPort Connector Digital RGB DisplayPort Complies with Standard V1.1a, applicable to HDCP V1.3
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
, 1920x1080*
1
(60 Hz), 1080p*
1
,
1080i*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz
VGA*
2
15pin Mini D-sub Analog RGB 0.7 Vp-p/75 ohm
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
, 1920X1080*
1
(60Hz)
Sync Separate: TTL level (Pos./Neg.)
Composite sync on Green Video: 0.3 Vp-p Neg.
HDMI HDMI Connector Digital YUV
Digital RGB
HDMI
VGA60, SVGA60, XGA60, WXGA60, SXGA60*
1
, UXGA60*
1
, 1920x1080*
1
(60 Hz), 1080p*
1
,
1080i*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz, 480i@60Hz
DVD/HD*
2
15pin Mini D-sub Component Y: 1.0 Vp-p/75ohm, Cb/Cr (Pb/Pr): 0.7 Vp-p/75 ohm
HDTV/DVD: 1080p*
1
, 1080i*
1
, 720p@50Hz/60Hz, 576p@50Hz, 480p@60Hz, 576i@50Hz,
480i@60Hz
VIDEO1
VIDEO2*
2
BNC
15pin Mini D-sub
Composite 1.0 Vp-p/75 ohm
NTSC/PAL/SECAM/4.43NTSC/PAL60
S-VIDEO*
2
15pin Mini D-sub S-VIDEO Y: 1.0 Vp-p/75 ohm C: 0.286 Vp-p/75 ohm (NTSC), 0.3 Vp-p/75 ohm (PAL/SECAM)
NTSC/PAL/SECAM/4.43NTSC/PAL60
Output Signal
DVI DVI-D 24pin Digital RGB DVI (HDCP)
AUDIO
AUDIO
Input
STEREO Mini Jack Analog Audio Stereo L/R 0.5 Vrms
HDMI Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
DisplayPort Connector Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit)
AUDIO
Output
RCA (L/R) Analog Audio Stereo L/R 0.5 Vrms
Speaker Output Internal Speaker 8 W + 8 W
Control RS-232C In:
RS-232C Out:
LAN:
Remote IN:
Remote OUT:
9 Pin D-sub
9 Pin D-sub (with daisy chain)
RJ-45 10/100 BASE-T
Stereo Mini jack 3.5
Stereo Mini jack 3.5
Power Supply 2.0 - 0.8 A @ 100-240V AC, 50/60Hz
Operational Environment Temperature:
Humidity:
Altitude:
5 - 40°C / 41 - 104°F, 5 - 35°C / 41 - 95°F (in portrait orientation with Slot 2 type PC*
3
)
20 - 80% (without condensation)
0 - 3000 m (Brightness may decrease with altitude)
Storage Environment Temperature:
Humidity:
-20 - 60°C / -4 - 140°F
10 - 90% (without condensation) / 90% - 3.5% x (Temp - 40°C) regarding over 40°C
Dimension 786.8 (W) x 476.2 (H) x 93.5 (D) mm / 31.0 (W) x 18.7 (H) x 3.7 (D) inches
Weight 12.4 kg (27.3 lbs)
VESA compatible mounting interface 200 mm x 200 mm (M6, 4 Holes)
Power Management VESA DPM
Plug & Play VESA DDC2B, DDC/CI, DisplayPort
Accessories Setup manual, Power Cord, Video Signal cable, Remote Control, AA Battery x 2, CD-ROM
NOTE: Technical specifi cations are subject to change without notice. *1: Compressed image.
*2: Common terminal.
*3: Please ask your NEC sales representative for detailed information.
