2) The monitor replies Schedule to the controller.
Header Message Check code
Delimiter
SOH-'0'-'0'-Monitor ID-'B'-'1'-'8'
STX-'C'-'3'-'1'-'3'-PG-ON HOUR-ON MIN-
OFF HOUR-OFF MIN-INPUT-WD-FL-P MODE-ETX
BCC CR
Header
SOH (01h): Start of Header
'0' (30h): Reserved
'0' (30h): Message receiver is the controller.
Monitor ID: Indicate a replying Monitor ID.
Ex.)
 When this byte is set to 'A', the replying Monitor ID is '1'.
'B' (42h): Message type is "Command reply".
'1'-'8'(31h, 38h): Message length
Message
STX (02h): Start of Message
'C'-'3'-'1'-'3' (43h, 33h, 31h, 33h): Schedule read reply command
PG-ON HOURS-ON MIN-OFF HOURS-OFF MIN-INPUT-WD-FL-P MODE: Schedule data
PG: Program No.
'0'-'0'(30h, 30h): Program No.1
|
'0'-'6'(30h, 36h): Program No.7
ON_HOUR: Turn on time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): ON timer isn't set.
ON_MIN: Turn on time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59
'3'-'C'(33h, 43h): On timer isn't set.
OFF_HOUR: Turn off time (hour)
'0'-'0'(30h, 30h): 00
|
'1'-'7'(31h, 37h): 23 (=17h)
'1'-'8'(31h, 38h): Off timer isn't set.
OFF_MIN: Turn off time (minute)
'0'-'0'(30h, 30h): 0
|
'3'-'B'(33h, 42h): 59 (=3Bh)
'3'-'C'(33h, 43h): Off timer isn’t set.
INPUT: Timer input
'0'-'0'(30h, 30h): DVI
'0'-'1'(30h, 31h): (DISPLAY PORT)
'0'-'2'(30h, 32h): VGA
'0'-'3'(30h, 33h): RGB/HV
'0'-'4'(30h, 34h): HDMI
'0'-'5'(30h, 35h): DVD/HD1
'0'-'6'(30h, 36h): DVD/HD2
'0'-'7'(30h, 37h): SCART
'0'-'8'(30h, 38h): VIDEO1
'0'-'9'(30h, 39h): VIDEO2
'0'-'A'(30h, 41h): S-VIDEO
'0'-'B'(30h, 42h): OPTION DTV
'0'-'C'(30h, 43h): OPTION COMPONENT
'0'-'D'(30h, 44h): OPTION DIGITAL
'0'-'E'(30h, 45h): OPTION ANALOG
WD: Week setting
bit 0: Monday
bit 1: Tuesday
