NEC MultiSync X461UNV Manual

(28/43)
'0'-'0'(30h, 30h): DVI
'0'-'1'(30h, 31h): (DISPLAY PORT)
'0'-'2'(30h, 32h): VGA
'0'-'3'(30h, 33h): RGB/HV
'0'-'4'(30h, 34h): HDMI
'0'-'5'(30h, 35h): DVD/HD1
'0'-'6'(30h, 36h): DVD/HD2
'0'-'7'(30h, 37h): SCART
'0'-'8'(30h, 38h): VIDEO1
'0'-'9'(30h, 39h): VIDEO2
'0'-'A'(30h, 41h): S-VIDEO
'0'-'B'(30h, 42h): OPTION DTV
'0'-'C'(30h, 43h): OPTION COMPONENT
'0'-'D'(30h, 44h): OPTION DIGITAL
'0'-'E'(30h, 45h): OPTION ANALOG
WD: Week setting
bit 0: Monday
bit 1: Tuesday
bit 2: Wednesday
bit 3: Thursday
bit 4: Friday
bit 5: Saturday
bit 6: Sunday
EX.
'0'-'1'(30h, 31h): Monday
'0'-'4'(30h, 34h): Wednesday
'0'-'F'(30h, 46h): Monday, Tuesday, Wednesday and Thursday
'7'-'F'(37h, 46h): Monday to Sunday
FL: Option
bit 0: 0:once 1:Everyday
bit 1: 0:once 1:Every week
bit 2: 0:Disable 1:Enable
* When bit 0 and bit 1 are '1', it behaves as Everyday.
EX.
'0'-'1'(30h, 31h): Disable, Everyday
'0'-'4'(30h, 34h): Enable, once
P MODE: Picture mode
'0'-'0'(30h, 30h): HI_BRIGHT
'0'-'1'(30h, 31h): STANDARD
'0'-'2'(30h, 32h): sRGB
'0'-'3'(30h, 33h): CINEMA
'0'-'4'(30h, 34h): ISF_DAY
'0'-'5'(30h, 35h): ISF_NIGHT
'0'-'6'(30h, 36h): AMBIENT_1
'0'-'7'(30h, 37h): AMBIENT_2
* If picture mode setting is skipped, the reply also won’t have picture mode data.
* Skipped message length is '1'-'8'(31h, 38h).
ETX (03h): End of Message
Check code
BCC: Block Check Code
Refer to the section 4.5 “Check code” for a BCC calculation.
Delimiter
CR (0Dh): End of packet
3)
The controller requests the monitor to write Enable/Disable Schedule.
Header Message Check code
Delimiter
SOH-'0'-Monitor ID-'0'-'A'-'0'-'A'
STX-'C'-'2'-'1'-'5'-PG-EN-ETX BCC CR
Header
SOH (01h): Start Of Header
