NEC MultiSync
®
X463UN
1. Power (AC in)
2. Main switch (on/off)
3. LAN with SNMP
4. Remote control in / out
5. External control RS-232 in / out
6. DisplayPort in / out
7. DVI in / out
8. HDMI in
9. RGB in
10. RGB HV in (RGB, Component, Composite)
11. Composite in
12. Composite out
13. Audio out
14. S-Video in
15. Audio in
16. External speaker
SPECIAL CHARACTERISTICS
Advanced fan control, Copy display settings through RS232,
DICOM support, Hardware colour calibration possible, Input name
adjustment, Matrix memory, NaViSet Administrator 2, OSD
rotation for portrait mode, PIN as theft protection, Programmable
ambient light sensor, Rapid input switching, Scheduler, Screen
saver functions, Super slim bezel with 5.9 mm between contents
and 5.7 mm bezel width, TileMatrix (10 x 10), User input priority
definition, Various picture in picture options
Energy Efficiency Ambient light sensor; LED backlight;
Carbon savings meter
Ecological Materials Mercury free; Optional feet; Manuals on
CD
Ecological Standards Energy Star 5.1
Technical Specification NEC MultiSync
®
X463UN
DISPLAY
Panel Technology
S-PVA TFT with direct white LED backlights
Active Screen Area (W x H) [mm]
1,018.4 x 572.5
Screen Size [inch/cm]
46 / 116.8
Aspect Ratio
16:9
Brightness (shipping) [cd/m
2
]
500, (700 max)
Contrast Ratio (typ.)
3500:1
Viewing Angle [°]
178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Response Time (typ.) [ms]
8
Panel Refresh Rate [Hz]
60
SYNCHRONISATION RATE
Horizontal Frequency [kHz]
31.5 - 91.1
Vertical Frequency [Hz]
50 - 85
RESOLUTION
Native Resolution
1920 x 1080 at 60 Hz
Supported on digital and analogue inputs (PC)
1920 x 1080; 1680 x 1050; 1600 x 1200; 1400 x 1050; 1366 x 768; 1280 x 1024;
1280 x 960; 1280 x 800; 1280 x 768; 1280 x 720; 1024 x 768; 800 x 600; 720 x
576; 720 x 400; 640 x 480
Supported on digital inputs (Video)
1920 x 1080i (59.94/60)16:9; 1920 x 1080i (50)16:9; 1920 x 1080p (59.94/60)
16:9; 1920 x 1080p (50)16:9; 1920 x 1080p (23.97/24)16:9; 1920 x 1080p (25)
16:9; 1920 x 1080p (29.97/30)16:9; 1280 x 720p (59.94/60)16:9; 1280 x 720p (50)
16:9; 720 x 576p (50)16:9; 720 x 480p (59.94/60)16:9
CONNECTIVITY
Input Video Analogue
1 x D-sub 15 pin; 1 x S-Video; Composite (BNC); RGBHV for PC and Component/
Composite (BNC)
Input Video Digital
1 x DVI-D (with HDCP); 1 x HDMI 1.3 (with HDCP); 1 x DisplayPort (with HDCP)
Input Control
LAN 100Mbit; remote control wire (3,5mm jack); RS232
Output Video Analogue
Composite (BNC)
Output Video Digital
1 x DisplayPort (with HDCP); 1 x DVI-D (with HDCP)
Output Control
remote control wire (3,5mm jack); RS232
Remote Control
LAN with SNMP; RS-232C (9-pin D-sub) Input and Output; Remote Control IR
(internal/external (optional) sensor)
OPTION SLOT
Slot Technology
Dual Slot (STv1 + STv2); (STv2 compatible with Intel / NEC OPS standard)
Inrush Current [A]
max. 10
Power Consumption [W]
max. 61
Voltage / Current [V/A]
16/4
ELECTRICAL
Power Consumption on Mode [W]
120 shipping; 260 (max.)
Power Savings Mode [W]
< 0.5 (ECO Standby); < 1
Power Management
VESA DPMS
ENVIRONMENTAL CONDITIONS
Operating Temperature [°C]
+0 to +40
Operating Humidity [%]
20 to 80
Storage Humidity [%]
10 to 90
Storage Temperature [°C]
-20 to +60
MECHANICAL
Dimensions (W x H x D) [mm]
Without stand: 1,024 x 578.6 x 118.1
Weight [kg]
Without stand: 24.4
Bezel Width [mm]
1.9 bottom/right; 3.8 top/left; 5.7; Content to content 5.9
VESA Mounting [mm]
300 x 300 (FDMI); 4 holes; M6
AVAILABLE OPTIONS
Option Slot
DVBT-Tuner; DVI daisy chain board; HDSDI 1.5 and 3G; Intel Atom, Celeron and
Core CPUs
ADDITIONAL FEATURES
Colour Versions
Black Front Bezel, Black Back Cabinet
Safety and Ergonomics
CE; TÜV GS; C-tick; Energy Star 5.1; FCC Class B; UL/C-UL or CSA; PSB; VCCI;
RoHS
Shipping Content
Display; DVI-D cable; interface cover; Power Cable; Free LAN control software
(download); CD-ROM (User Guides/Manuals)
Signal Cable: 3,5 mm jack
Warranty
3 years warranty incl. backlight
