121
CRT beam to adjusted
• You can turn on or off each CRT beam (R, G, B).
6 Press and hold the CTL then press any one of the CURSOR
buttons to select the position to be adjusted. (The marker on the
selected side will turn to a solid color.)
• CTL + .......... Top
• CTL + .......... Bottom
• CTL + .......... Right
• CTL + .......... Left
7 Use the CURSOR buttons to adjust the selected position.
• Adjust the center, edge, and corner in this order. If necessary,
repeat the procedure.
• Press CURSOR or button to adjust the selected position
horizontally or vertically.
Press CURSOR or button to adjust the selected position
diagonally.
8 To end this mode, press the END button.
• Whenever the END button is pressed, the menus will sequence
in this order:
“REF. ADJUST” menu→Source screen
• If the “RETURN USER MODE?” menu appears, use the
CURSOR or button to select either “YES” or “NO” and
then press ENTER. This will exit the REF. ADJUST mode.
Items to select
• YES ...........When you try to enter the ADJUST mode the next
time, you will need to re-enter your passcode.
• NO .............When you try to enter the ADJUST mode the next
time, you will not need to re-enter your passcode.
ASTIG
- EDGE -
CRT - R -
SCREEN - TOP -
60%
HV
SK
40%
ASTIG
- CORNER -
CRT - R -
SCREEN - BR -
60%
40%
HV
SK
REFERENCE ADJUSTMENT
