77
5 Use the CURSOR or button to select one of the three items:
S2, S1, and OFF, and then press ENTER.
Items to select
S2 .............. Identifies squeeze and letter box signals.
S1 .............. Identifies a squeeze signal only.
OFF ............ Does not identify any S-video signal.
6 To end, press the END button.
• Whenever the END button is pressed, the menus will sequence
in this order:
“OPTION” menu → “ADJUST” menu → Source screen
• If the “RETURN USER MODE?” menu appears, use the
CURSOR or button to select either “YES” or “NO” and
press ENTER. This will exit the ADJUST mode.
Items to select
• YES ......... When you try to enter the ADJUST mode the next
time, you will need to re-enter your passcode.
• NO ........... When you try to enter the ADJUST mode the next
time, you will not need to re-enter your passcode.
NOTE :
• The input signal must be compatible with the S2/S1 MODE
standard.
Refer to the user manual included with the connected equip-
ment for more information.
• The identification function may not work correctly with a non-
compatible signal. If this happens, select “OFF” from the “S-
VIDEO MODE SELECT” menu.
RETURN USER MODE?
YES NO
S2
S1
OFF
S-VIDEO MODE SELECT
SETTING
To Next Page
