20
Example of LAN connection
(A) Example of wired LAN connection
WIRELESS
USB(LAN)
WIRELESS
LAN
Server
Hub
LAN cable (not supplied)
2. Installation and Connections
(B) Example of wireless LAN connection
(Network Type
→
Infrastructure)
To make connection with a wireless LAN via a wireless access point, you need to select the Infrastructure mode.
From the menu, select [SETUP]
→
[INSTALLATION]
→
[NETWORK SETTINGS]
→
[WIRELESS]
→
[ADVANCED]
→
[CONNECTION]
→
[NETWORK TYPE]
→
[INFRASTRUCTURE].
PC with wireless
LAN card inserted
PC with built-in wireless
LAN function
Wireless access point
Wired LAN
USB Wireless LAN Unit
Downloaded From projector-manual.com NEC Manuals
