NEC Versa Series - Identifying the Switch Settings

3-20 Using the BIOS Setup Utility
3.
Remove the screw and lift off the memory module bay cover. See “Identifying the
Switch Settings” for information about each setting.
4.
Reassemble the NEC Versa components as follows.
! Replace the memory module bay cover.
! Replace the screw.
! Turn the system over.
Identifying the Switch Settings
The following list identifies each switch setting and its function.
! Switch 1 — Password override — The default setting is “OFF.” If you forget your
password and cannot access the data on your NEC Versa, change the setting to
“ON” and your current password is erased.
! Switch 2 — Keyboard select; Default is “ON” for U.S. 86 key keyboard and “OFF”
for European keyboard.
! Switch 3 — Not assigned; must be “OFF.”
! Switch 4 — Keyboard select 2; Default is “ON” for US and “OFF” for European
keyboards.
! Switch 5 — Reserved for factory use; Default is “ON.”
! Switch 6 — Logo select; Default is “OFF.”
Default switch settings
