8
Num Lock indicator LED
Caps lock indicator LED
Battery
Battery pack removal
Please remove the battery pack according to the following illustration.
LED state Computer State
On (Green) <Num Lock> is on (Part of the keyboard can be used as
a numeric keypad))
Off <Num Lock> is off
LED state Computer State
On (Green) <Caps Lock> is on (All letters are entered as capital
letters))
Off <Caps Lock> is off (All text input is lowercase letters))
• Never touch the battery slot terminals. It may cause contact failure.
• Before installing or removing the battery pack, disable the "Fast Startup" function.
For more detailed information, please refer to "Disabling the "Fast Startup" function"
(p.24).
Battery lock
Battery eject lever
1
2
3
To Next Page
