- 9 -
REMOVING BOBBIN CASE AND BOBBIN
1. Raise the needle to its highest
position and open shuttle race cover.
3. Release the latch and the bobbin will fall out
easily.
INSERTING BOBBIN INTO BOBBIN CASE
1. Pull 5 cm of thread from bobbin and
insert it into bobbin case as shown.
3. Pull the thread through the slot and under the
tension spring and draw out about 10 cm of
thread.
2. Open the hinged latch of the bobbin
case and pull the bobbin case out of
the machine.
2. Guide the end of thread into the slot.
Slot
Hinged latch
5 cm
10 cm
Tension spring
To Next Page
