Exhaust Hose Reel 865
3.4Technical data
Item Dimension
Weights
• Without hose 31 kg (68 lbs)
• With hose and nozzle 40 – 50 kg (82 – 110 lbs)
Duct connection Ø 160 mm (6.3 in)
Recommended airflows
• For cars, 100 mm (4”) hose
400 – 600 m
3
/h (235 – 350 cfm)
• For trucks, 125/150 mm (5”/6”) hose
800 – 1200 m
3
/h (470 – 700 cfm)
Ambient temperature -10 °C to +50 °C (15 °F to 120 °F)
Exhaust temperature Maximum 300 °C
Hose temperature resistance
• HoseNR-CP 150 °C (300 °F) continuously
• HoseNFC-3 300 °C (570 °F) continuously
Power supply 100 V, 115 V, 200 V, 230-240 V AC 1-phase, 50/60 Hz
Power consumption Maximum 325 VA
Protection class IP 44
Noise level Measured according to ISO 11201. < 70 dB(A).
Material recycling Reels without hose: 100 weight-%
4Installation
See Figure2.
A* Short model.
A** Wide model.
*** Wall holder for the hand control.
NOTE!
The maximum mounting height is depending
on the hose length and weight. The maximum
allowed uncoiled free-hanging hose weight in-
cluding nozzle is 30 kg. Choose such mount-
ing height so that the hose in uncoiled position
can be connected to the vehicle’s exhaust pipe
without being stretched.
1 Make sure that the surface, on which to mount the
reel, is level. Drill 4 holes, using the hole template
which comes in the package.
2 Fit the mounting brackets in such a way that it will
make the reel hanging horizontally. Ensure that
suitable fixing bolts are used considering the ceil-
ing or wall construction material. The bolts must
each stand a tractive force of a minimum of 6500
N.
3 Use approved lifting equipment to lift the reel.
Fasten the reel in the brackets.
4 Make sure that the indicator is not pointed at a
light source, it may interfere with the function of
the remote control.
4.1Mounting the hose
See Figure3. When the Exhaust Hose Reel 865 has
been mounted and connected to the power supply,
the hose should be fitted (concerning reels delivered
without hose only). It should be noted that the reel
can not be rotated by hand.
EN
13
