Exhaust Hose Reel 865
3.4Technical data
Exhaust Hose Reel 865
Weight, with hose 23 kg (51 lbs)
Weight: short reel, with hose and nozzle 30–40 kg (66–82 lbs)
Weight: wide reel, without hose 31 kg (68 lbs)
Weight: wide reel, with hose and nozzle 40–50 kg (82–110 lbs)
Recommended mounting height Maximum 6 m (20 ft)
Duct connection Ø 160 mm (6.3 in)
Recommended airflows, cars, 75–100 mm (3"–4") hose
400–600 m
3
/h (235–350 cfm)
Recommended airflows, trucks, 125–150 mm (5"–6") hose
800–1200 m
3
/h (470–700 cfm)
Operating temperature –10 °C to +50 °C (15 °F to 120 °F)
Hose temperature resistance, Hose NR-CP or NTP 150 °C (300 °F) continuously
Hose temperature resistance, Hose NFC-3 300 °C (570 °F) continuously
Noise level, measured according to ISO 11201. < 70 dB(A)
Material recycling, reels without hose 100 weight-%
4Installation
4.1 Installing Exhaust Hose Reel 865
See Figure2.
A* Short model.
A** Wide model.
NOTE!
Maximum mounting height for the reel is 6 m.
1 Make sure that the surface, on which to mount the
reel, is level. Drill four holes, using the hole tem-
plate which comes in the package.
2 Fit the mounting brackets in such a way that will
make the reel hang horizontally. Ensure that suit-
able fixing bolts are used considering the ceiling
or wall construction material. The bolts must each
stand a tractive force of a minimum of 6500 N.
3 Use approved lifting equipment to lift the reel.
Fasten the reel in the brackets.
4 Fit the hose stop on the hose in such a position
that the nozzle stops in the desired position when
the hose has recoiled.
4.2Safety lock
See Figure3–Figure4.
WARNING!Risk of personal injury
The reel is equipped with a safety lock that
should be used during service or repair work on
the reel, for example when mounting or chan-
ging the hose. NB! When changing the spring
the spring power must be completely neutral-
ized (instruction is delivered together with the
spare part spring).
4.3Mounting the hose
See Figure3. When the reel has been mounted on wall
or ceiling, the hose is mounted in the following way
(concerning reels delivered without hose only):
1 Fasten the hose with a hose clip on the connecting
piece inside the drum.
2 Pull out the safety lock.
3 Wind all the hose on, by turning the drum in the
direction of the arrow. Ensure that the hose only
forms one layer on the drum.
4 Tension the spring. See Figure6 and Sec-
tion4.7Adjustment of spring tension.
5 Fit the hose stop on the hose in such a position
that the nozzle stops in the desired position when
the hose has recoiled.
6 Fit the nozzle.
