N16/24/27/29/40
Motor power
See product label
Motor speed See motor label
Votage/Phase
See motor label
Frequency
See product label
Rated current See motor label
N16
29 lbs (13 kg)
N24
37 lbs (17 kg)
N27
37 lbs (17 kg)
N29 - 3 hp (2.2 kW)
71 lbs (32 kg)
N40 - 2 hp (1.5 kW
55 lbs (25 kg)
N40 - 3 hp (2.2 kW
64 lbs (29 kg)
(–22°F to +104°F (–30°C to +40°C)
ÁÊŴÇÏT½ÅȽʹÌÍʽ
max+140°F)(+60
0
C)
N16
74-76 dB(A)
N 24
75-79 dB(A)
N27
75-79 dB(A)
N 29
70-80 dB(A)
N 40
60-80 dB(A)
** According to ISO 11203, with duct connected to inlet and outlet.
4
4.1
Installation
Mounting instructions N16/24/27/29/40
WARNING! Risk of explosion.
The fan must not be installed in an environment with danger of explosion or be used
to transport flammable or explosive dust or gases.
WARNING! Risk of personal injuries.
Guard nets must be mounted on the inlet and outlet of the fan, unless the fan is fixed
and/or directly connected to ducting system. See Figure 4 page 4.
WARNING! Risk of personal injuries.
A duct or hose must be fitted on the N40 fan inlet. See Figure 5 page 5.
Ensure the fan has not been damaged during transport. Fans without a stand are
designed to be mounted directly to other Nederman products.
Nederman Customer Service & Technical Support techsupport.us@nederman.com +1 (336) 821-0800
11
Max Airflow
N16 - 3/4 hp (0.55 kW)
750 cfm (1250 m
3
/hr)
N24 - 1 hp (0.75 kW)
900 cfm (1500 m
3
/hr)
N24 - 1.5 hp (1.1 kW) (230/460V
1030 cfm (1750 m
3
/hr)
N27 - 1.5 hp (1.1 kW) (110V)
825 cfm (1400 m
3
/hr)
N27 - 2 hp (1.5 kW) (230/460/575V)
1150 cfm (1950 m
3
/hr)
N29 - 3 hp (2.2 kW)
1765 cfm (3000 m
3
/hr)
N40 - 2 hp (1.5 kW)
1470 cfm (2500 m
3
/hr)
N40 - 3 hp (2.2 kW)
2350 cfm (4000 m
3
/hr)
3.3
Technical Data
Table 3-1:
Weights:
Noise Level: **
Temperature
