Quick start guide
Pre-Amplier
AAMP2411BK
For more information see the extended manual
online: ned.is/aamp2411bk
Intended use
The Nedis AAMP2411BK is a pre-amplier that you can use to
connect an (extra) turntable to your speakers.
The product is intended for indoor use only.
The product is not intended for professional use.
Any modication of the product may have consequences for
safety, warranty and proper functioning.
Specications
Product Pre-Amplier
Article number AAMP2411BK
Input impedance 47 KΩ / 220 pf
RIAA deviation response ± 0.5 dB
THD < 0.5 %
Input sensitivity 3.0 mV
Input overload margin 20 dB
Nominal output 300 mV
Maximum output power 1.8 V / 1 KHz
Signal / noise ratio > 85 dB
Output impedance 1 KΩ
Connections 1 RCA input
1 RCA output
Power input 12 VDC ; 0.5 A
Main parts (image A)
1 Power indicator LED
2 Power switch
3 RCA input
4 RCA output
5 Ground wheel
6 Power input
7 Power adapter
