nedis IREX100BK - Operation; Specifications; Maintenance; Warranty

3
Application 2:
1. ConnecttheIRextensioncableand
IR receiving sensor to the infrared
receiver as shown in the picture.
2. PlacetheIReyespreciselyinfrontof
the IR sensors of the equipment.
3. Connectthepowersupply.
Operation:
15°
15° 15°
15°
0.3m 5.7m
6m
Specications:
• OperatingVoltage:
• PowerConsumption:
• EffectiveOperatingRange:
• InfraredTuningFrequency:
• ExtenderProbe:
DC 12V/ 250 mA
1W(max)
6M(min)
30~60KHz
3IReyeson2metercable
Safety precautions:
Disconnecttheproductfrommainsandotherequipmentifaproblemshouldoccur.Donotexposetheproduct
to water or moisture.
Maintenance:
Cleanonlywithadrycloth.Donotusecleaningsolventsorabrasives.
Warranty:
Noguaranteeorliabilitycanbeacceptedforanychangesandmodicationsoftheproductordamagecaused
due to incorrect use of this product.
