Page 7 of 12
EasyConnect Components
There are 3 different groups of EasyConnect. One prepared for Neeets control keypads (EcHo, EcHo Plus and
SieRRa II), and one with two power plugs.
Number: Description
1 Sturdy retractable lid - Opens and closes manually. All connectors are covered when closed,
leaving a solid flat surface with only a small opening for lifting the cover
2 Outer flange - Fits over mounting surface for clean appearance
3 Height adjustment screws – Adjusts height of internal connector plate
4 Connector box - Provides space for up to six AV connectors
5 Frame for Neets Control – EcHo, Echo Plus or SieRRa II (EU control system)
6 Built-in AC line Outlet with either EU, DK, UNI, or CN power socket
3
3
4
5
2
2
6
6
6
3
3
1
1
4
Neets EasyConnect - for Neets Control Keypad
Neets EasyConnect - Power
