en Cleaning and servicing
28
Removing telescopic rails
1. Pull out the telescopic rail.
2. Move the lock in the direction of
the arrow and loosen the pin
from the rear .
3. Push in the telescopic rail.
4. Push the telescopic rail backwards
above the rear pin and disen-
gage .
Installing telescopic rails
1. Place the extended telescopic rail
on the front pin and pull it for-
wards slightly to lock in place .
2. Place the telescopic rail on the
rear pin and push the locking
mechanism back .
