Page 9
6.2.2. Errors table
(display)
The following messages appear on the display in case of error:
FULL – radio remote control memory full
Err - the radio remote control is not recognized in either delete or write
t--- - temperature out of range >60 °C < 0 °C
6.3. Settable functions
6.3.1. In1, In2 - Parameters P009 – P010
For reasons of simplicity, from now on the opening of the window is associated with
forward movement of the actuator and closing of the window is associated with its
backward movement.
Two voltage-free control inputs “in1” and “in2” are provided on the terminal block and can
be configured in the following modes described below.
When the inputs are activated, the respective message appears on the display: “in1” and
“in2”.
- Open/Close function in self-hold mode (n.o.). (P009=1, P010=1)
Upon closure of the contact - and immediate release - the station instructs the
forward/backward operation of the motor for the motor work time set in P101.
If you would like to stop the movement of the motor, just give another pulse to the
command of that particular operation direction. Vice versa, if you give a pulse in the
opposite direction of movement, the motor changes operation direction.
- Deadman Open/Close function (n.o.). (P009 =1, P010=1)
Upon closure of the contact - and retention for more than 2 seconds - the station
instructs the forward/backward operation of the motor until the contact itself is
released.
- Step function on IN1 (n.o.). (P009=2, P010 =3)
With the IN1 input only, the motor can be controlled according to the step sequence,
that is open-stop-close-stop-open... with each closure and release of the contact itself.
- Block automatic movements from IN1 sensors function (n.c.) (P009=3)
This function provides that the motor movement occurs only by means of the PIK radio
remote control present on the radio remote controlled version.
If activated (opening of the contact), it allows to block operation of the
rain/wind/light/temperature sensors until the contact is closed.
- Safety function - IN2 Photocell (n.c.). (P010=2, P009=2,)
This function is used to manage a closing safety, that is, if the contact is opened
during the closing phase, the motor stops and does not continue in the same direction
until the n.c. contact is restored (e.g. photocell). When setting this function, it is
mandatory to manage IN1 in step mode. Or manage the movements of the motor
through the PIK radio remote control present in the radio remote controlled version.
- IN2 Timer function (n.o.). (P010 = 3 or P010=4)
With this function when the input IN1 is selected the Step sequence becomes
operational automatically, regardless of the mode set with the parameter P009 of IN1.
Alternatively, the movements of the motor can be controlled with the PIK radio remote
control present in the radio remote controlled version.
Page 10
The IN2 Timer function provides for a voltage-free (also known as “potential-free”)
“n.o.” contact at the input. Upon activation of the timer the contact closes and the
station instructs the opening (P010=3) or closing (P010=4) of the motor.
6.3.2. Rain sensor - Parameters P005 – P104
Upon activation of the rain sensor, the respective message “r” appears on the display,
The RAIN input is set up to be connected to a device that detects rain and provides a
voltage-free n.o. contact. The opening/closing action of the window can be set using
the P104 menu.
Supply voltage 12V for rain sensor
Tension (V) Maximum Current (mA)
12V 100mA
Please contact Nekos technical office to use rain sensors other than NSR1
In case of rain with the window closed, the window can be reopened by
excluding intervention of the rain sensor for the time set in parameter P005.
Caution.
If you do not want to use this function, leave the parameter P005 = 0
6.3.3. Wind sensor - Parameter P103
Upon activation of the wind sensor, the respective message appears on the display: “u
XX”, where XX is the value of the detected wind speed expressed in Km/h.
The intervention threshold of the wind sensor is set by parameter P001 within the range 5
Km/h - 50 Km/h. The opening or closing of the window can be set by P103. Temporary
wind gusts do not activate the function.
6.3.4. Temperature sensor – Parameters P002 – P003 – P007
Upon activation of the sensor, the respective message appears on the display: “t XX”
where XX is the detected temperature in °C (degrees Celsius or Centigrade).
The input is set up for a temperature sensor of the type NTC 10 Kohm at 25 °C.
The station manages two temperature thresholds; a minimum threshold settable by the
P002 menu and a maximum threshold settable by P003. The two thresholds can be set
within the limits provided by the menu with an automatic shift set at 2 °C minimum.
It is advisable to keep the two thresholds with a margin greater than the minimum 2 °C .
The opening or closing of the window can be set by the parameter P007.
6.3.5. Brightness sensor – Parameters P004 – P008
Upon activation of the sensor, the respective message appears on the display: “S XX“
where XX is the detected brightness value in KLUX. The lux values of brightness are
indicated in the table below.
