Page 15
Activation of the timer command affects all the actuator outputs of the associated
modules: exit 1-exit 2 of the first module, exit 3-exit 4 of the second module and exit 5-
exit 6 of the third module.
The opening or closing of the windows can be set by the parameters P105-P205-P305-
P405-P505-P605.
6.3.5. Sensor priority – Parameter P006
By means of parameter P006, higher priority can be assigned to one of the sensors
(wind-rain-timer) in case events occur simultaneously.
Attention. In case events occur simultaneously, the unit will follow these priorities:
1. General manual command
2. Single manual command
3. Remote control
4. Sensors
5. Aeration
6. Restoration
6.3.6. Exit reset time – Parameters P102, P202, P302, P402, P502, P602
After intervention of the sensors (rain, wind) and the reset time set by parameter P102
– P202 – P302 – P402 – P502 – P602 has passed, the window returns to the previous
scenario.
Caution.
If you do not want to use this function, leave the parameter P102 – P202 – P302 – P402
– P502 – P602 = 0
With P102 – P202 – P302 – P402 – P502 – P602 = 0, when one or more sensors
intervene the window goes to the position instructed by the sensor with higher priority
and remains there.
6.3.7. Output ventilation time – Parameters P106, P206, P306, P406,
P506 and P606
The Ventilation function is for automatically ventilating the room. To activate this
function, press the F1 and arrow
▲buttons in
sequence on the radio remote control.
The window opens for the set time and then closes again automatically, unless other
commands are given. If a rain sensor signal or a manual or radio-controlled command
is given, the ventilation function is interrupted; to restore the function, the button
sequence must be repeated.
The set time also includes the opening time of the actuator.
6.3.8. Other parameters – Parameters P101, P201, P301, P401, P501,
P601, Add, dEL, ReTx, rESE
- The parameter P101 – P201 – P301 – P401 – P501 – P601 is used to set the
work time of the exit.
- The parameter “Add” of the menu is used to save one or more channels of the
PIK radio remote control in the station.
Page 16
- The parameter “dEL” of the menu is used to delete one or more PIK radio remote
controls saved previously.
- The parameter “ReTx” of the menu is used to delete all PIK radio remote controls
from the memory.
- The parameter “rESE” of the menu is used to restore the factory-set values
(Default).
6.4. Saving a PIK radio remote control
This paragraph concerns only the KL_R or KH_R units equipped with PIK radio remote
control.
THE CONTROL UNITS LEAVE THE FACTORY WITH THE REMOTE CONTROL ALREADY INSERTED IN
THE MEMORY; CARRY OUT THE MEMORIZATION PROCEDURE ONLY IF YOU WANT TO ASSOCIATE
OTHERS.
The remote electronic control provided with KL_R and KH_R units is equipped with 30
selectable channels. Each command channel is connected to one unit exit.
Opening/closure/stop of each exit can be commanded using arrow ▲/▼ and STOP
buttons.
For more details on the characteristics and operation of the PIK radio remote control,
consult the instructions manual provided with the radio remote control itself; not all the
functions of the radio remote control are listed in this manual.
The KL_R or KH_R station can accept maximum up to 6 PIK radio remote controls.
Memorizing procedure:
- Equip yourself with the radio remote control, checking beforehand that it is
working, has charged batteries and is in good condition.
- Select the “Add” item in the unit menu.
- Press the “OK” button.
- The message “Push” will appear on the display.
- On the PIK radio remote control (see the instructions provided with the radio
remote control), select any channel between CH1 and CH6 and press any one of
the ▲/▼ ARROW or STOP buttons on the PIK for about 1 second.
- The “OK” message will appear on the unit display, indicating that the memorizing
process was successful.
- The radio remote control is now saved and the actuators are controlled by the
respective channels. (CH1=exit 1; CH2=exit 2….. CH6=exitr 6).
In case of full memory “FULL” message appears on the display.
In case of remote control not associated “Err” message appears on the display.
Repeat the procedure for any other radio remote controls.
