Nelson SC40A - User Operations and Controls; 13. USER INSTRUCTIONS; 14. CONTROL AND COMMAND PANELS

12
13. USER INSTRUCTIONS
14. CONTROL AND COMMAND PANELS
MOD. Standard:
MOD. Water softener:
Table:
1. ALIVE MACHINE INDICATOR GREEN LIGHT
2. ON-OFF SWITCH
3. CYCLE START BUTTON(FOR EQUIPMENT WITH DRAINING PUMP)
4. OPERATING MACHINE INDICATOR YELLOW LIGHT
5. READY MACHINE INDICATOR YELLOW LIGHT
6. SHORT CYCLE(1)-LONG CYCLE(2)SWITCH
7. CYCLE START REGENERATION BUTTON(AND DRAINING FOR EQUIPMENT WITH
DRAINING PUMP)
8. REGENERATION CYCLE IDICATOR YELLOW LIGHT
