Version: 7.0
16.02.2017
2
Technical parameter
Working voltage: DC 9V
Current:
Quiescent current: ≤ 10 uA
Alarming Current: ≤ 20 mA
Alarming Decibel: ≥ 85 dB / 3m
LED Indicator: LED (red)
Low voltage Alarming: ≤ 7.3V
Working Temperature: -10°C to approx. 40°C
Working humidity: ≤ 95° RH
EN
Note: If the battery is not installed correctly, the alarm will not work and may be
destroyed. If the alarm operates smoothly, the red LED will ash once in about
43 seconds.
Dimensions (mm)
Ø 101,00
30,60
70,00
