MERLIN STEALTH Installer Options
GATE 2 DELAY TIME
The time delay for the gate to stay open before the alarm is activated, can be changed by
pressing the 1 key, followed by the 2 key. Select the desired time delay from the table and
press the corresponding number from 0 to 9 followed by the # key. The keypad will beep twice
to indicate that the new setting was accepted.
Example: To change the Gate Delay Time to 4 minutes,
enter 1 2 8 #
HIGH POWER FENCE VOLTAGE
The open circuit fence voltage can be changed by pressing the 0 key, followed by the 5 key.
Select the desired voltage from the table and press the corresponding number from 0 to 9
followed by the # key. The keypad will beep once to indicate that the setting was accepted.
Example: To change open circuit Fence Voltage to 6kV6 on a M15, enter 0 5 2 #
M15 & M25 M18 & M28
Typical readings Typical readings
0 2 Sec
1 5 Sec
2 10 Sec
3 30 Sec
4 45 Sec
5 1 Min
6 2 Min
7 3 Min
8 4 Min
9 4 Min 30 Sec
V peak
open
circuit.
Volts
V peak
500 ohm
load
Energy
(500 ohm
load) J
0 6000 3900 2.50
1 6300 4150 2.80
2 6600 4300 3.00
3 7100 4500 3.20
4 7500 4850 3.70
5 7750 5050 4.00
6 7900 5200 4.20
7 8100 5300 4.40
8 8300 5450 4.60
9 8500 5600 4.80
V peak
open
circuit.
Volts
V peak
500 ohm
load
Energy
(500 ohm
load) J
0 8000 auto 7100 6.8
1 7000 4500 3.20
2 7700 4950 3.70
3 8200 5300 4.20
4 8500 5650 4.80
5 8900 5950 5.20
6 9200 6850 6.40
7 9300 7100 6.80
8 9300 7350 7.30
9 9300 7600 7.60
