ORIGINAL MANUAL (INSTRUCTION)
LASER DISTANCE METER :
75-203
CAUTION: Before using the device read this manual carefully and keep it
for future reference. Failure to follow safety rules from this manual may cause tool
damage or body injuries.
WARNING: Do not look directly at the source of laser beam.
Follow the below safety rules.
1. Do not modify the tool.
2. Use the laser device in accordance with the manufacturer’s instructions.
3. Do not intentionally point the laser beam at people or animals.
4. Do not point the laser beam at bystanders’ or animals’ eyes. Laser radiation
may damage your vision.
5. Always make sure the laser beam is not directed at reective surfaces.
Reective surface could project the beam at operator or bystanders.
6. Do not allow children to operate the device. Do not allow children in the
workplace when setting up and using the device.
7. When not using, store the device in a dry place, beyond reach of children.
8. Do not replace the laser unit with device of other type. All repairs must be
carried out by the manufacturer service.
9. The tool is equipped with class 2 laser device compliant with EN 60825-
1:2014.
INTENDED USE
The device is designed for personal use only. It can be used to
measure length, area and volume. Additionally, the range nder features
option of indirect measurements, that uses Pythagorean theorem to calculate
height or distance. Dynamic measurement allows for continuous
measurements. Additionally, the device is equipped with automatic level that
allows for continuous readout of the device angle. The device also features
USB socket that allows to charge the device batteries easily.
Observe the following instructions when working for the best device
operation. Use other than described below is not allowed and may cause damage
to the product.
Parameter Value
Measurement range 0.2 to 40 m
Measurement accuracy +/- 2mm/10m*
Operating temperature 0
0
– 40
0
Measurement memory storage 20
Laser class 2
