NEOHIPO AM02 - User Manual

NEOHIPO AM02
12 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
AM02 User Manual
AM02
SD
AM02
MIC TONE
MUSIC TONE
POWER
O
AUTO
USB
CHMODE CH
MIC-1 MIC-2
Karaoke
M .VOL
O 1O
M.BASS
-10 +1O -10 +1O
-10 +1O
-10 +1O0 +1O
M.TREBLE
ECHO
TREBLE BASS
MIN
MAX
VOLUME

Table of Contents

Questions and Answers

  • C
    Courtney DickersonJul 27, 2025
    Why is there no sound coming from my NEOHIPO AM02?
    • B
      Bryan AdkinsJul 27, 2025
      There could be several reasons for the lack of sound from your NEOHIPO Amplifier. First, ensure that all sound source and speaker connections are properly connected. Next, verify that the volume control is not set to the minimum position and adjust it accordingly. Also, check that the impedance of the speakers connected to the amplifier is between 4 and 8 ?. Finally, if the amplifier has been running for a while, it may have switched off due to overheating. In this case, turn the amplifier off, allow it to cool down with proper ventilation, and then turn it back on.

Summary

Front Panel Controls

Power ON;OFF Switch

Controls the main power state of the amplifier.

Microphone Volume Control

Microphone Inputs

Master Volume Control

Adjusts the overall output volume.

Media Player Controls

Back Panel Connections

Line Input Terminals

Speaker Output Terminals

Connects passive speakers to the amplifier.

12 V DC Power Input

Port for connecting a 12V DC power adapter.

AC Power Input Socket

Standard socket for mains AC power connection.

Remote Control Operations

Remote Power Control

Turns the amplifier on/off remotely.

Remote Mode Switching

Remote Volume Control

Initial Setup and Startup

Bluetooth Connectivity Guide

FM Radio Operation

USB and TF Card Playback

Product Specifications

Troubleshooting Common Issues

NEOHIPO AM02 Specifications

General IconGeneral
Device Name:Bluetooth 2.0 CH Amplifier
Included In The Packaging:AM021 、Remote Control1、 User Manual 1、 power cable1
Input Mode:RCA\BT\FM\USB\ TF CARD\MIC
Max Output Power:300W
Frequency Range:20Hz-20KHz (+/-3dB)
THD:≤ 0.1%
SNR:≥ 85dB
Rms:15W*2
Recommended speaker Power:50-80W
Recommended speaker Impedance:4-8 Ω
power Adapter:AC 110V-240V
DC Input :DC 12V
Bluetooth Range:Up to 10m
Weight and Dimensions IconWeight and Dimensions
Dimensions:25316370mm
View in Manual
