EN |
NERONE
| User and Maintenance Manual
40
6.7 HEATING ELEMENTS REMOVAL AND REPLACEMENT
Switch-off the oven and disconnect it from the electrical network before replacing the heating
resistances.
1) Unscrew manually the 2 mounting pawls of the internal baking pans supports and extract them delicately.
2) With an Allen wrench No. 5 unscrew the central screw that fi xes the fans protection.
3) Remove delicately the fans protection.
4) Unscrew the 2 nuts fi xing the fans to the 2 motors and extract the 2 fans.
5) Remove the rear back of the oven and disconnect the wires that connect the resistances.
6) Unscrew the 3 fi xing screws, for each of the 2 resistances and extract them delicately.
Replace the resistances and reassemble the oven components by carrying out inversely the procedure described above.
1
2
3
4
5
6
7
