Ness S2 - Page 7

7
When enabled, the S2 Buzzer will sound and the Alarm Output will be activated if there are 10 successive invalid
Card presentations or 10 successive incorrect PIN numbers entered within a 10 minute period
10
–
Site
Code
Setting
(for Wiegand Output
)
(Can only be done in Master Programming Mode)
When a valid User Code is entered the Wiegand Output will transmit the Site Code along with the 4 Digit PIN
number entered as the Wiegand Card Number
Example - If the PIN used is 8888 and the Site Code is 029 then the full 8 digit, 26 Bit Wiegand number
transmitted on the Wiegand Output is 029 08888
The default Site Code is 029 however an alternative Site Code may be programmed
Press
81
Enter Required Site Code (0
-
>
255)
#
Site Code must be between 0 and 255
11
–
Se
tting the Address of the Reader
(Defaul
t 0)
(Can only be done in Master Programming Mode)
When using S2 with security equipment that supports addressable readers such as Ness D8XD / 16XD Panels,
Ness 6DA controllers etc it may be necessary to set the address of the reader
When programmed to Address 0 (Default) the Wiegand Output uses standard 26 Bit Wiegand protocol.
When set to address 1, 2 or 3 the Wiegand Output appends Ness encrypted protocols to S2’s address
0 - S2 Address 0 (Default)
1 - S2 Address 1
2 - S2 Address 2
3 - S2 Address 3
Pre
ss
82
Enter Address (0
-
>
3)
#
(Factory Default is
0
-
St
andar
d 26 Bit Wiegand
output
)
12
–
Alarm Output Time
(Default 1 Minute)
(Can only be done in Master Programming Mode)
This option sets the Alarm Output Time (duration) of S2’s Alarm Output
Press
9
Enter Alarm
Time in Minutes (1
-
>
3)
#
(Factory Default is
1
-
1 Minute)
