26 NETAFLEX™ 3G USER MANUAL
SPARE PARTS
Main parts (described on pages 24-25)
* For spare part ordering call your local Netafim™ representative having at hand the
Serial Number of your NetaFlex™ 3G.
Only with this number we can supply the correct part for your specific NetaFlex™ 3G.
The Serial Number is inscribed on the side of the switchbox (3530-_________).
Part Description Cat. No.
1 Frame for NetaFlex™ 3G Not supplied as spare part
2 Control unit Per NetaFlex™ 3G Serial Number*
3 Water Tank 200L - blue, 55 cm diam. 114 cm high 77600-001986
4.1 System Inlet
Per NetaFlex™ 3G Serial Number*
4.2 Float Valve
4.3 Float valve to tank adaptor
4.4 Difuser Kit
5 Lower manifold to tank adaptor 33240-006400
6.1 Inlet to pump
Per NetaFlex™ 3G Serial Number*
6.2 Tank Outlet
7.1 Outlet from pump adaptor
7.2 Outlet from pump manifold
7.3 Check valve
7.4 Outlet from check valve
7.5 Outlet from pump manifold to filter adaptor
7.6 Filter
7.7 Filter to upper manifold adaptor
7.6.1
Screen filter element PVC-U 100 mesh 775 4 0 - 0 07110
Screen filter element Stainless Steel 240 mesh 77540 - 007120
8 Upper / lower manifold 33240-002100
9 Venturi See page 28
10 Dosing channel See page 27
11 Reducer 50mm - 1/2" 33240 -002251
12 PVC threaded plug 1/2" - male 77300-016010
13 Plug 1/4" 77300-016000
14 Control tube elbow connector 8*1/4 FT58 71000-031970
15 Pressure gauge - 250 GLZ 8 bar (116 PSI) 1/4" BSP 77540-003350
16 PVC threaded plug 3/4" - male 77400-027100
17.1 EC/pH manifold Per NetaFlex™ 3G Serial Number*
17.2 Union adaptor set for EC/pH sensor 33120-008500
17.3
Galcon EC sensor, Jumo - 12 mm ,temperat comp. 10K 45000-006690
4G, ABB,
Fertmaster
EC sensor, Jumo - 12 mm ,temperat comp. PT 100 45000-006705
17.4
ABB pH sensor, Jumo - 12mm, plastic, bared wires 45000-006701
4G, Galcon,
Fertmaster
pH sensor, Jumo - 12mm, glass, W/BNC
connection
45000-006692
18 Water level float 1/2" 75080-002900
19 Penetration seal for Lower manifold to tank adaptor 77600-014000
20 Penetration seal for Tank Inlet/Outlet Per NetaFlex™ 3G Serial Number*
21 Penetration seal for Overflow assembly 77600-006510
22 Low level switch 77100-007930
23 Low level switch casing 33240-006220
24 Overflow assembly 33240-006450
25 System pump See page 29
26 Female connector 8*1/2 76400-002465
