Thumbscrew
Controller module cover.
Step 3: Replace the NVMEM battery
To replace the NVMEM battery, you must remove the failed battery from the controller module and install the
replacement battery into the controller module.
Use the following video or the tabulated steps to replace the NVMEM battery:
Animation - Replace the NVMEM battery
1. Locate and replace the impaired NVMEM battery on your controller module.
It is recommended that you follow the illustrated instructions in the order listed.
