NetApp AFF A150 - Page 445

As you insert the connector, you should feel it click into place; if you do not feel it click,
remove it, turn it around and try again.
Steps
1. Use the following animation or illustrations to cable your controllers to two NS224 drive shelves.
Animation - Cable two NS224 shelves - ONTAP 9.8 and later
443
