Door grounding screw with grounding wire spade
Grounding wire
Frame grounding wire lug
Top front door hinge with hinge pin held by retaining clip
Lock catch
3. Reverse the hinge pin from the top hinge:
a. Lift the hinge pin and expose the retaining clip on the hinge pin shaft.
1484
