Air duct locking tabs
Slide air duct towards fan modules
Rotate air duct towards fan modules
Step 2: Replace the boot media
You locate the failed boot media in the controller module by removing Riser 3 on the controller module before
you can replace the boot media.
You need a Phillips head screwdriver to remove the screw that holds the boot media in place.
1. Locate the boot media:
955
