Technical specifications
The following are the technical specifications for your router and satellite
Technical specifications for router model MR80
The following table shows the technical specifications for the router.
Table 6. Technical specifications for the router
DescriptionFeature
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic
DNS, UPnP, and SMB
Data and routing protocols
North America: 120V, 60 Hz, input
UK, Australia: 240V, 50 Hz, input
Europe: 230V, 50 Hz, input
All regions (output): 12V, 2.5A DC output
Power adapter
5.51 x 5.51 x 3.62 in (140 x 140 x 92 mm)Dimensions
1.4 lb (639 g)Weight
0° to 35°C (32º to 95ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15, Subpart B, Class B
IECS-003, Class B
EN 55032, EN 55035, Class B
AS/NZS CISPR 32, Class B
Electromagnetic emissions
RJ-45 port supporting 10BASE-T, 100BASE-TX, and
1000BASE-T
LAN
RJ-45 port supporting 10BASE-T, 100BASE-TX, and
1000BASE-T
Internet (WAN)
Maximum wireless signal rate complies with the IEEE 802.11
standard.
3
WiFi
2.4 GHz: Max 600 Mbps
5 GHz Front haul: Max 1200 Mbps
5 GHz Back haul: Max 1800 Mbps
Radio data rates
IEEE 802.11b/g/n 2.4 GHz–1024 QAM support
IEEE 802.11 a/n/ac 5 GHz–1024 QAM support
Data encoding standards
User Manual147Supplemental Information
Nighthawk Tri-band Mesh WiFi 6
