NETGEAR Nighthawk AX5 User Manual

Top panel LEDs and buttons
The status LEDs and two buttons are located on the top panel of the router.
Figure 2. Top view
Table 1. LED descriptions
DescriptionLED and Button
•
Solid white. The router is ready.
•
Blinking white. The router is not ready, firmware is upgrading, or the Reset
button was pressed.
•
Off. Power is not supplied to the router.
Power LED
•
Solid white. The Internet connection is ready.
•
Blinking white. The port is sending or receiving traffic.
•
Off. No Ethernet cable is connected between the router and the modem.
Internet LED
User Manual10Hardware Setup
Nighthawk AX5 5-Stream WiFi Router

NETGEAR Nighthawk AX5 Specifications

General

Beamforming	Yes
MU-MIMO	Yes
OFDMA	Yes
WiFi Technology	802.11ax
Number of Ethernet Ports	4 Gigabit Ethernet ports
Security	WPA3, VPN support
USB Ports	1 x USB 3.0 port
Antenna	4 external antennas
Memory	512 MB RAM
Weight	1.28 lb (580 g)
