Table 3. Factory default settings (Continued)
Default settingFeature
Auto for 2.4 GHz, CH 44 for WW SKU, and CH 153 for
North America SKU
RF channel
Up to 600 Mbps at 2.4 GHz
Up to 3600 Gbps at 5 GHz
Operating mode
1
Maximum wireless signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
Technical Specifications
Table 4. Router specifications
DescriptionFeature
TCP/IP, RIP-1, RIP-2, DHCP, PPPoE, PPTP, Bigpond, Dynamic DNS, UPnP, SMBv1,
SMBv2, and SMBv3
Data and routing protocols
North America: 100-120V, 50/60 Hz input
UK, Australia: 220V, 50/60 Hz, input
Europe: 220V, 50/60 Hz input
All regions (output): 12V/2.5A DC output
Power adapter
11.65 x 8.11 x 2.25 in (295.8 x 206 x 57.2 mm)Dimensions
1.25 lbs (566 g)Weight
0° to 40°C (32º to 104ºF)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15 Class B
EN 55022 (CISPR 22), Class B C-Tick N10947
Electromagnetic emissions
Compatible with 10BASE-T, 100BASE-TX, 1000BASE-T, or RJ-45LAN
Compatible with 10BASE-T, 100BASE-TX, 1000BASE-T, or RJ-45WAN
Maximum WiFi signal rate complies with the IEEE
®
802.11 standard.
2
•
2.4GHz AX: 2x2 (Tx/Rx) 1024/256-QAM 20/40MHz, up to 600 Mbps
•
5GHz AX: 3x3 (Tx/Rx) 1024-QAM 20/40/80/160MHz, up to 3603 Mbps
•
Backwards compatible with 802.11a/b/g/n/ac WiFi
WiFi
User Manual161Supplemental Information
Nighthawk AX5 5-Stream WiFi Router
