NETGEAR Nighthawk X4S

1
Hardware Features
Top and Side Panels
The LEDs, buttons, and USB ports are shown in the following figure.
For more information about the LEDs and buttons on the top panel,
see Top Panel LEDs and Buttons on page 2.
Rear Panel
The rear panel connections and buttons are shown in the following
figure.
LEDs WPS button
with LED
Reset button
Ethernet
ports 1–4
Internet
port
Power
On/Off
button
Power
connector
LED Indicator
On/Off switch
eSATA
port
USB 1
port
USB 2
port
WiFi button
with LED
