NETGEAR Nighthawk X4S

3
LED Description
eSATA LED
• Solid white. An eSATA device is connected and is ready.
• Blinking white. An eSATA device is plugged in and is
trying to connect.
• Off. No eSATA device is connected.
Ethernet ports
1–4 LEDs
The LED color indicates the speed: white for Gigabit
Ethernet connections and amber for 100 Mbps or 10 Mbps
Ethernet connections.
• Solid. A powered‑on device is connected to the Ethernet
port.
• Blinking. The port is sending or receiving traffic.
• Off. No device is connected to this Ethernet port.
WiFi On/Off
button with LED
Pressing this button for two seconds turns the 2.4 GHz and
5 GHz WiFi radios on and off.
If this LED is lit, the WiFi radios are on. If this LED is off, the
WiFi
WPS button with
LED
This button lets you use WPS to join the WiFi network
without typing the WiFi password. The WPS LED blinks
white during this process and then lights solid white.
