NETGEAR Nighthawk X6 R7900

1
LEDs
The LEDs on the top of the router light to indicate router activity.
You can use the LED On/Off switch on the rear panel of the router
to turn the LEDs on the top of the router on or off.
Note: The Power LED stays lit even if the LED On/Off switch is in the
Off position.
LED On/O switch
Power LED
Internet LED
2.4 GHz WiFi LED
5 GHz WiFi 1 LED
5 GHz WiFi 2 LED
USB 3.0 port LED
Guest WiFi LED
Ethernet ports 1–4 LEDs
WiFi On/O button and LED
WPS button and LED
