NETGEAR Orbi RBR50 Quick Start Guide

Ring LED (not shown in image)
Sync button (also used for WPS connection)
Internet port (the Orbi satellite does
not include an Internet port)
Ethernet ports
Support
Thank you for purchasing this NETGEAR
product. You can visit
www.netgear.com/support to register
your product, get help, access the latest
downloads and user manuals, and join our
community. We recommend that you use
only ocial NETGEAR support resources.
For the current EU Declaration of
Conformity, visit
http://support.netgear.com/app/answers/
detail/a_id/11621/.
For regulatory compliance information, visit
http://www.netgear.com/about/
regulatory/.
See the regulatory compliance document
before connecting the power supply.
NETGEAR INTL LTD
Building 3, University Technology Centre
Curraheen Road, Cork, Ireland
NETGEAR, Inc.
350 East Plumeria Drive
San Jose, CA 95134, USA
© NETGEAR, Inc., NETGEAR and the NETGEAR Logo
are trademarks of NETGEAR, Inc. Any non‑NETGEAR
trademarks are used for reference purposes only.
September 2016
All Set Up!
Orbi Router Overview
Orbi router
(Model RBR50)
Orbi satellite
(Model RBS50)
Ethernet cable
Power adapters (2) (varies by region)
Orbi Satellite OverviewPackage Contents
2
1
3
4
1
2
3 4 5
6
7
8
2
1
6
4 5 7
8
USB port
Power On/O button and Power LED
DC Power connector
Reset button
5
6
7
8

NETGEAR Orbi RBR50 Specifications

General

WiFi Technology	802.11ac
Coverage	Up to 5, 000 sq ft
Ethernet Ports	4 Gigabit Ethernet ports
USB Ports	1 USB 2.0 port
Memory	512MB NAND Flash and 512MB RAM
Antenna	Internal antennas
Security	WPA2-PSK
Beamforming	Implicit & Explicit Beamforming for 2.4GHz & 5GHz bands
WiFi Speed	AC3000 (1733 + 866 + 400 Mbps)
Weight	1.96 lb
Processor	710MHz quad-core processor
Dimensions	6.7 x 3.1 x 8.9 inches
