CHAPTER 2
CONFIGURATION
This chapter describes how to set up the ASP7101-IP for connectivity to the LAN and
configure the attached hardware in its environment.
Initial Network Setup
Connect the ASP7101-IP to a PoE capable network switch or via a mid-span device.
To logon for the first time, open a web browser and type the IP address of the panel
in the address bar. Each unit is pre-configured with a default IP address of
10.100.1.172 when it leaves the factory. The default username and password are as
follows:
Username: netgenium
Password: netgenium
The home page provides basic information on the controller such as software
version serial number etc. Navigation around the menu structure is via the tabs
shown at the top of the home page. Each tab redirects the browser to the master
page for the configuration section selected. In each section a sub menu is accessible
via the links on the left of the page.
