Wireless N ADSL2+ Modem Router Quick Installation Guide
2
Name Status Indication
PWR On Power is on.
Off Power is off.
ADSL
Flash The ADSL negotiation is in progress.
On The LINE port is linked up.
Off The LINE port is linked down.
Internet
Flashing Data is being transferred over the
Internet.
On The modem router is initializing in the
first 10 seconds when power is up.
Or a successful PPP connection has been
built.
Off
There is no successful PPP connection or
the modem router works on Bridge mode.
WLAN
Flash There is wireless data being transmitted.
On The wireless function is enabled but no
data is being transmitted.
Off The wireless function is disabled.
WPS Off WPS connection process is not activated.
There's no wireless device trying to
connect to the network by WPS function.
Flash WPS function is activated. The modem
router's waiting for the WPS connection
from a wireless device. This process will
last in the first 2 minutes.
To Next Page
