NH-310C HPNA3.1 over Coaxial Cable (HCNA) End Point USER’S MANUAL Ver. A7
6
Chapter 2. Hardware Description
This section describes the important parts of the modem. It features the front indicators and rear connectors.
NH-310C Outward
2.1 Front Panel
The front panel provides a simple interface monitoring of the end point. (Figure 2.1)
Figure 2.1: NH-310C Front Panel
