left in the container
Spraying with horizontal
objects (fig.7)
Turn ascending pipe A forwards.
Spraying overhead objects (fig.6)
Turn ascending pipe A to point
backwards.
4. Fill container with coating material.
Screw firmly onto spray gun.
5. Place the spray gun in the spray gun
holder.
6. Only place the device on an even
and clean surfaces. Device could
suck to dust ,etc.
7. Before connecting to the mains
ensure that the mains voltage
corresponds with the details on the
rating plate.
8. Remove the spray gun from the
spray gun holder and point at object
to be sprayed. Turn on using.
9. ON/OFF switch on the device.
10. Adjust the spraying pattern and amount of material; set the amount of air and
pressure, seefig.8,9,10 and the description page 11.
