Adjusting the spray gun
Choice of spraying effects
A =vertical flat jet
for horizontal surfaces
B =horizontal jet
for vertical surfaces.
C =round jet
for corners and edges and other badly accessible places
Adjusting the required spray effect
With the union nut (3) loosed, turn air cap (1) to the required spray pattern.
Caution:
Never open trigger when making adjustments on the air cap.
Adjusting the amount of material
Adjust the amount of material by turning the adjustment screw.
